Name：HIGH TEMPERATURE and HIGH PRESSURE CERAMIC BALL VALVE

Category：Ceramic Valves > Ceramic Ball Valves

HIGH TEMPERATURE & HIGH PRESSURE CERAMIC BALL VALVE

Applicatios: Applied to any media, but HF (Hydrofluoric Acid), with Max. Temperature 425℃ and Max. Pressure 11.0 Mpa. This valve has uncomparable advantages under using in heavy-duty, severe service.

Structure:3-part type,Flange,According to ASME B16.34-2004Test,According to API 598-2004.

Per customer‘s actual working conditions,the valves can be perfectly customized.

Using the high precision machining process, the natural advantages of structural ceramics makes the valve to easily gain perfect sealing and light torque, the scratch of sealing surface and the ball core locking can be effectively avoided .

The tenon type sealing structure is adopted between seat and body lined, which ensures the good sealing while the valve is working in high pressure .

Adopting the high neck structure of stuffing box ensure a double valve stem seal, with using graphite packing, the valve sealing can be highly ensured in the condition of high temperature and high pressure To ensure security, anti-blowout structure design is adopted, prevent the valve stem spewing out of the valve under high working pressure .
