Electric furnace

Model

TC-1515A

TC-2025A

TC-2035A

TC-2045A

TC-3045A

TC-3050A

TC-4050A

TC-1515B

TC-2025B

TC-2035B

TC-2045B

TC-3045B

TC-3050B

TC-4050B

Basic Parameter

Normal Operation Temp

Type A: 1500℃

Type B: 1600℃

Max. Operation Temp

Type A: 1600℃

Type B: 1700℃

Temp Distribution

About ±3℃ (working zone, normal temperature, uncharged pit)

Heat Time/Temperature

A

60min/1500℃

3hr/1500℃

B

60min/1600℃

4hr/1600℃

Atmosphere

Atmospheric environment (any kinds of atmosphere required by customers)

Inside Dimensions(mm)

W

150

200

200

200

300

300

300

400

H

150

200

200

200

300

300

300

400

D

150

250

350

450

350

450

500

500

Heater

MoSi2 Heating Element

Furnace Capacity

A

4KW

5.5KW

7KW

9KW

9KW

10KW

11KW

20KW

B

4.5KW

6KW

8KW

9.5KW

10KW

11KW

12KW

22KW

Control Section

Control System

PID Full-automatic Control, One-phase

PID Full-automatic Control, Three-phase

Instrumentation

Alarm Function

Over temperature alarm, abnormal conditions alarm etc.

Furnace Advantages

Introduce Japanese advance furnace making technology, and German flame-retardant fiber board, which in good effect of saving energy and low consumption of energy;YT Torch MoSi2 heating element, which has the characteristics of reliable performance;Adopt 0.2 degree Japanese PID intelligent temperature controller, 100 sections programmable;Silicon controlled transformer, even can work regularly in a very wide range of electric power grain option, and can adjust heating power in full automatic continuously and smoothly. Having adaptability, control accuracy±1℃;5’ LCD paperless recorder, reappearance all details of programming and recording curve; the historical data could be import to computer by USB;

Double shells structure, the outer casing temperature lower than 45℃

Beautiful Design
