INNOVACERA Pyrolysis Hot Pressing Boron Nitride Threaded Pipe Tube

SKUBN Tube
Online quote
Price MOQ Lead Time Customization Sample
Negotiable Contact Supplier Contact Supplier - -
Packing specification
Net weight Gross weight Dimension Remarks
Payment Terms
Shipping terms

Product Description

Model
BN Tube
Brand
INNOVACERA
Origin
China • Offer certificat of origin
Port
xiamen
Features

As a new type of advanced ceramic material, Boron Nitride has characteristics like ultra-long heat resistance and excellent thermal shock resistance. Also, it is easy to process into various complex shapes and has excellent corrosion resistance and wear resistance.
It has high resistance to wetting of molten metal, slag, glass, etc.
Product Details

Xiamen Innovacera Advanced Materials Co., Ltd (INNOVACERA) locates in the Special Economic Zone of Xiamen, Fujian Province. There are rich resources and convenient transportation.

INNOVACERA engages in R&D, manufacturing and selling the products of advanced ceramic materials, including Alumina, Zirconia, Boron Nitride, Silicon Nitride, Machinable Glass Ceramic, and other advanced materials. Through different manufacturing processes, we supply metallized ceramic components, alumina heater, ceramic pump components, and other ceramic components as request.



Hexagonal Boron Nitride has a microstructure similar to that of Graphite. In both materials this structure, made up of layers of tiny platelets, is responsible for excellent machinability and low-friction properties. we called hexagonal boron nitride (HBN) or white graphite.



Material of Boron Nitride Ceramics

Pyrolytic Boron Nitride: 99.99% Boron Nitride*
99 Boron Nitride: Boron Nitride + Boric Oxide(B2O3)
CABN: Boron Nitride + Calcium Borate
ALBN: Boron Nitride + Al2BO3
ZRBN: Boron Nitride + Zirconium Oxide + Boric Oxide(B2O3)
ZABN: Boron Nitride + Zirconium Oxide + Aluminum Nitride + Al2BO3
SCBN: Boron Nitride + Silicon Carbon + Al2BO3

Product parameters

Content 99%BN BN+AL BN+SIC BN+ZRO2 BN+ALN
Density 1.95-2.0

2.25-2.35

2.35-2.5

2.9-3.0 2.5-2.6
Max Use Temper 2100 1700 1700 1800 1800
Thermal Expansion 1.5 1.9 4.0 6.0 3.0
Compreesive strength 58 150 175 200 185
Thermal Conduvity 30 35 40 30 55
Application Furance Powder Metalurgy Powder Metalurgy Metal Casting High Temperature Equipment
